| 型号 |
扭矩范围 Nm |
最高转速 rpm |
伸缩长度 mm |
设批头快换 |
偏置距离 mm |
最小安装 中心距 mm |
传感器类型 | 精度 | |
|
直 柄 式
|
PTQ-CSF-0080N-0-S10-015-B | 2-8 | 3000 | 15 | HEX1/4" | - | 37 | 动态 | 精度±2.5% 工艺条件下 Cmk≥1.67 |
| PTQ-CSF-0200N-0-S20-015-B | 4-20 | 1764 | 15 | S 3/8" | |||||
| PTQ-CSF-0350N-0-S20-050-B | 7-35 | 1118 | 50 | ||||||
| PTQ-CSF-0500N-0-S30-050-B | 10-50 | 1950 | 50 | S 1/2" | 55 | ||||
| PTQ-CSF-0900N-0-S30-050-B | 20-90 | 1118 | 50 | ||||||
| PTQ-CSF-1400N-0-S30-050-B | 30-140 | 608 | 50 | ||||||
| PTQ-CSF-2000N-0-S40-050-B | 40-200 | 450 | 50 | S 3/4" | |||||
| PTQ-CSF-3150N-0-S40-050-B | 63-315 | 460 | 50 | 84 | |||||
| PTQ-CSF-4500N-0-S40-050-B | 90-450 | 312 | 50 | ||||||
| PTQ-CSF-6000N-0-S40-050-B | 120-600 | 234 | 50 | ||||||
|
偏 置 式 |
PTQ-COF-0080N-0-S10-015-B | 2-8 | 3000 | 15 | HEX1/4" | 52.4 | 32 | ||
| PTQ-COF-0200N-0-S20-015-B | 4-20 | 1764 | 15 | ||||||
| PTQ-COF-0350N-0-S20-050-B | 7-35 | 1118 | 50 | ||||||
| PTQ-COF-0500N-0-S30-050-B | 10-50 | 1950 | 50 | 78 | 47 | ||||
| PTQ-COF-0900N-0-S30-050-B | 20-90 | 1118 | 50 | ||||||
| PTQ-COF-1400N-0-S30-050-B | 30-140 | 608 | 50 | S 3/8" | |||||
| PTQ-COF-2000N-0-S40-050-B | 40-200 | 450 | 50 | HEX1/4" | |||||
| PTQ-COF-3150N-0-S40-050-B | 63-315 | 460 | 50 | 101.2 | 58 | ||||
| PTQ-COF-4500N-0-S40-050-B | 90-450 | 312 | 50 | ||||||
| PTQ-COF-6000N-0-S40-050-B | 120-600 | 234 | 50 |
