In modern industrial manufacturing—especially in automotive, aerospace and precision-equipment sectors—bolting is far more than simply “making it tight”. It is a safety-, reliability- and life-critical process. For joints with demanding specifications, “step-by-step tightening” and “multi-step tightening” are two indispensable control strategies. Although the names are similar, their objectives, application moments and the problems they solve are fundamentally different. Understanding the distinction is the first step toward world-class assembly quality.

1. Core concept: splitting the PROCESS versus splitting the FINAL-STAGE

Step-by-step tightening – splits the PROCESS
The complete movement of the bolt, from first engagement to final clamp load, is divided into several successive steps, each with its own speed, torque threshold and monitoring logic. The goal is an automated, error-proof and highly efficient rundown sequence.

Multi-step tightening – splits the FINAL-STAGE
After the bolt head has seated, the last plastic-flow phase is itself broken into two or three substeps. The purpose is to control material behaviour, improve final torque accuracy and increase joint reliability.

2. Step-by-step tightening: a refined roadmap that prevents errors before they happen

Typical roadmap:

1. Reverse search (reverse rotation at low speed)
   The socket and bolt head are aligned; cross-threading, socket mismatch or missing bolts are detected right at the start.

2. Slow thread engagement (low-speed forward)
   The bolt is gently run into the hole. Thread damage, burrs, or wrong length are identified before any harm is done.

3. High-speed rundown
   Once correct engagement is confirmed, speed is increased to bring the bolt to snug point in the shortest possible cycle time.

4. Low-speed final tightening
   Speed is reduced again for the final torque- or angle-controlled pull-up. Torque overshoot is avoided; thread stripping, missing washers, foreign particles or surface roughness anomalies are detected by watching the torque/angle signature.

Because every phase is monitored in real time, step-by-step tightening delivers 100 % in-line quality control and prevents defective joints from ever leaving the station.

3. Multi-step tightening: stress management for ultimate accuracy

Applied inside the low-speed final phase described above.

Two-step method
Step 1 – tighten to 50-75 % of target torque.
Pause – hold for several seconds to allow stress relaxation and settlement.
Step 2 – continue to the final target.
The pause lets early relaxation occur, so the final torque shows far less post-tightening decay and much higher repeatability.

Three-step method (also called an angle or yield-controlled variant)
Step 1 – tighten to an initial torque.
Step 2 – loosen (reverse rotate) by a defined angle.
Step 3 – retighten to the final torque or angle.
The loosening step removes thread-to-thread variability and uneven friction; the subsequent pull-up starts from a “clean” mechanical state, giving extremely consistent axial preload.

In practice the two philosophies are combined: the bolt is brought safely and quickly to snug point with a step-by-step sequence; then the very last clamping phase is executed with a two- or three-step strategy to lock in a stable and repeatable preload.
